76 APX 5X HLDR MET FLG SHKItem is usually in stock, but we'll be in touch if there's a problem
by Allied Machine
76 APX 5X HLDR MET FLG SHKItem is usually in stock, but we'll be in touch if there's a problem
by Allied Machine
$
1,485
00
/ 1
Quantity:
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
76 APX 5X HLDR MET FLG SHKItem is usually in stock, but we'll be in touch if there's a problem
by Allied Machine
Price:
$
1,485
00
/ 1
Part Number: 504Y911
UPC:
Vendor Item Number: W7605H-50FM
Custom: ALLW7605H-50FM
$
1,485
00
/ 1
Quantity:
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Product Variations (3)
Technical Details
Length:
23.25
Weight:
20.16
Industrial Category:
Machining
Industrial Subcategory:
Indexable Tools
Industrial Subtype:
Drill Bodies
Assembled overall length mm:
501.1
Assembled reference length mm:
421.1
Coolant Inlet Style Rear:
Through the Shank
Country Of Origin:
US
Deep Hole:
No
Drill depth mm:
415
Family Description:
Allied's APX drilling system is a modular tool designed for depths beyond the range of a traditional IC drill. The tool uses a fixed series body, with various heads that determine the cutting diameter. Bodies are available from stock with a 2.000"
Family Features Benefits:
*Allows for higher Spindle speeds and takes advantage of the power curve on modern CNC machines for maximum penetration rates on deep holes *A unique "X" locator on the Head to body connection allows for simple assembly and superior strength.
Flute Type:
Helical
Length Type:
5x?/td>
Maximum diameter inch:
3.2673
Maximum diameter mm:
82.99
Minimum diameter inch:
2.9918
Minimum diameter mm:
76
Package Qty:
1.00
Series:
76
Shank diameter mm:
50
Shank length mm:
80
Shank type:
Flanged
Unit Of Measure:
EA
Manufactured By:
Allied Machine
+
Additional Information
Product Overview
