3M™ Scotchlok™ Male Disconnect, MNG10-250DMIX, yellow, nylon insulated with insulation gripItem is usually in stock, but we'll be in touch if there's a problem
by 3M
3M™ Scotchlok™ Male Disconnect, MNG10-250DMIX, yellow, nylon insulated with insulation gripItem is usually in stock, but we'll be in touch if there's a problem
by 3M
Call for Price
Quantity:
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
3M™ Scotchlok™ Male Disconnect, MNG10-250DMIX, yellow, nylon insulated with insulation gripItem is usually in stock, but we'll be in touch if there's a problem
by 3M
Price:
Call for Price
Part Number: 40J9DRX
UPC:
Vendor Item Number: 7000133358
Call for Price
Quantity:
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Technical Details
Industrial Category:
Electrical Supplies
Industrial Subcategory:
Wire Connectors
Industrial Subtype:
Wire Disconnects
Barrel Inside Diameter:
0.250 Inch
Barrel Style:
Butted
Color Family:
Yellow
Conductor Size:
12 - 10 AWG
CSA File Number:
LR22190
ECCN:
EAR99
Fastener Orientation:
Male
Insulation Color:
Yellow
Insulation Material:
Nylon with Insulation Grip
Material:
Plastic
Maximum Recommended Voltage Rating:
600.0 V
Maximum Wire Gauge:
10 AWG
Minimum Order Quantity:
50
Minimum Wire Gauge:
12 AWG
Product Color:
Yellow
RoHS EU Comments:
RoHS 2011/65/EU compliant without exemption
Terminal Style:
Fully Insulated
Terminal Type:
Disconnect
UL File Number:
E70512
UPC Code:
00051128587935
Voltage Application:
Low Voltage
Manufactured By:
3M
+
Additional Information
- Accommodates wire sizes 12 to 10 AWG
- butted-seam barrel with a funnel-designed
- Corrosion resistance to water
- CSA Certified and RoHS 2011/65/EU Compliant
- fixtures or luminaires
- Made of electrolytic copper for good conductivity and has corrosion-resistant tin plating
- Mates with 0.25 in (0.64 cm) wide female tab
- Maximum Operating Temperature 221°F (105°C)
- Rated 600V for building wire and 1000V for signs
- salt
- seamless brass sleeve offers easy insertion of wires
- steam and other related contaminants
- This male disconnect terminal offers excellent holding force
- UL Listed
- Yellow nylon-insulated
Product Overview
3M™ Scotchlok™ Male Disconnect is an insulated disconnect which attaches to its mating part by slipping the tongue of the male part over the female tab. This disconnect offers superior holding force while allowing for quick and easy disconnect. Its electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion. The terminal has a fully insulated, nylon, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). 3M™ Scotchlok™ Male Disconnects are UL Recognized and CSA certified.
