3M™ Scotchcast™ Electrical Resin 260, 44.1 lb.(20 kg.)Item is usually in stock, but we'll be in touch if there's a problem
by 3M

3M™ Scotchcast™ Electrical Resin 260, 44.1 lb.(20 kg.)<span class=' ItemWarning' style='display:block;'>Item is usually in stock, but we&#39;ll be in touch if there&#39;s a problem<br /></span>

3M™ Scotchcast™ Electrical Resin 260, 44.1 lb.(20 kg.)Item is usually in stock, but we'll be in touch if there's a problem
by 3M

Call for Price
Quantity:
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item

3M™ Scotchcast™ Electrical Resin 260, 44.1 lb.(20 kg.)Item is usually in stock, but we'll be in touch if there's a problem
by 3M

    Price:
    Call for Price
    Part Number: 407YECG
    UPC:
    Vendor Item Number: 7100024957
Call for Price
Quantity:
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Technical Details
Industrial Category:
Adhesives, Sealants and Tape
Industrial Subcategory:
Glues and Cements
Industrial Subtype:
Epoxy
Applicable by Electrostatic Spray:
Yes
Applicable by Fluid Bed Dip:
Yes
Applicable by Venturi Spray:
Yes
Application:
Utilities & Power: Coatings for Insulation
Color Family:
Green
Cure Method:
Oven
ECCN:
EAR99
Flame Retardant:
No
Form:
Powder
Material:
Epoxy
Mining Sector Approval:
No
Product Type:
Electrical Resin
RoHS EU Comments:
RoHS 2011/65/EU compliant without exemption
Storage Time in Months:
24.0
Temperature Rating:
Class H (<=180 deg C)
Voltage Rating:
Insulating
What Needs to be Coated:
Other
Manufactured By:
3M
+
Additional Information
  • buss bars and toroid cores
  • Chemical- and moisture-resistant
  • Compatible with electrostatic spray
  • EIS Approved and RoHS 2011/65/EU Compliant
  • fluid bed dip and venturi spray
  • Has 12 to 16-second gel time at 380 °F (193 °C)
  • Heat-
  • stators
  • UL Listed
  • Useful for moisture-proofing and insulating armatures
  • Withstands temperatures of 356 °F (180 °C)
Product Overview
The 3M™ Scotchcast™ Electrical Resin 260 is a 1-part powder resin used for coating flat surfaces, corners and high points. This general-purpose epoxy-based, powder resin has a very low viscosity property, that makes it easy to infuse on any surface. The resin melts when it's heated, it flows to a controlled extent and then cures, bonding to the surface in a uniform, thick coating.The 3M Scotchcast Electrical Resin 260 has a low gel point rating to ensure a quick curing process. The resin is made from a fusion blend process which offers the components necessary to provide a complete cure and meet required performance properties. It provides a continuous, tough moisture and chemical resistant dielectric coating to a variety of substrates. It is ideal for applications that need excellent thermal shock and mechanical shock resistance. Its high dielectric strength offers excellent electrical insulating property to the resin, thus making it an ideal insulator for creating a barrier between 2 conductors. UL Listed and RoHS 2011/65/EU Compliant.
